Flanged Deep Groove Ball Bearings Economy Type

Brand :

MISUMI

Caution

Product Description

LOW-COST FLANGED BALL BEARINGS -DOUBLE SHIELD TYPE-:Related Image

[ M ]Material: SUJ2

Specifications

Part Number

CFL683ZZ

Part Number	d	D	B	D₁	C	r (min)	Basic Load Rating		Allowable Rotational Speed rpm (Ref.)	Relative Dimensions		Mass (g) (Ref.)	Unit Price
Part Number	d	D	B	D₁	C	r (min)	Cr (Dynamic) N	Cor (Static) N	Allowable Rotational Speed rpm (Ref.)	Ds (min)	R (max)	Mass (g) (Ref.)	Unit Price
CFL682ZZ	2	5	2.3	6.1	0.6	0.08	165	48	85000	2.7	0.08	0.22	320
CFL673ZZ	3	6	2.5	7.2	0.6	0.1	208	74	71000	3.6	0.08	0.33
CFL683ZZ		7	3	8.1	0.8	0.1	390	130	63000	3.9	0.1	0.53
CFL693ZZ		8	4	9.5	0.9	0.15	560	179	60000	4.2	0.15	0.97
CFL674ZZ	4	7	2.5	8.2	0.6	0.1	220	88	60000	4.6	0.08	0.35
CFL684ZZ		9	4	10.3	1	0.1	640	220	53000	5	0.1	1.14
CFL694ZZ		11	4	12.5	1	0.15	710	276	48000	5.2	0.15	1.96
CFL675ZZ	5	8	2.5	9.2	0.6	0.1	217	91	53000	5.6	0.08	0.41
CFL685ZZ		11	5	12.5	1	0.15	715	281	45000	6.2	0.15	2.18
CFL695ZZ		13	4	15	1	0.2	1080	430	43000	6.6	0.2	2.84	280
CFL676ZZ	6	10	3	11.2	0.6	0.1	465	196	45000	6.6	0.1	0.77	320
CFL686ZZ		13	5	15	1.1	0.15	1080	440	40000	7	0.15	3.04	300
CFL696ZZ		15	5	17	1.2	0.2	1350	530		7.6	0.2	4.26	280
CFL678ZZ	8	12	3.5	13.6	0.8	0.1	515	252		8.8	0.1	1.15	320
CFL688ZZ		16	5	18	1.1	0.2	1610	710	36000	9.6	0.2	4.47
CFL698ZZ		19	6	22	1.5	0.3	1700	1990	36000	10	0.3	8.3

[ ! ]kgf=Nx0.101972
