Proximity Sensor, Cylinder Shape

Capacitive sensors can detect not only various types of metal workpieces, but their electrostatic principle also makes them more suitable for detecting various non-metallic objects, through-barrier detection, and detecting targets inside different containers. They can reliably detect non-metallic objects such as plastic, wood, liquids, and paper, and can also detect different substances inside containers through non-metallic walls. Electromagnetic interference, water mist, dust, and oil stains have almost no effect on their normal operation, giving the product outstanding anti-interference capability. In addition, the potentiometer allows for sensitivity adjustment, and the product comes in a variety of sizes to meet customers' diverse needs, making its applications even more extensive. It has the characteristics of both a limit switch and a micro switch, while also offering sensing capabilities. It operates reliably, has stable performance, fast frequency response, long service life, strong anti-interference ability, and features such as waterproof, shockproof, and corrosion resistance.

Style	Shape	Detection Distance		Mounting Method	Output Method	Detection Frequency Hz	Wire Length
E-MSMC12-N01	Threaded Type M12		1 to 3 mm (Adjustable distance)	Shielded	NPN N.O.	50	2M
E-MSMC12-P01					PNP N.O.
E-MSMC12-N11			1 to 6 mm (Adjustable distance)	Non Shield	NPN N.O.
E-MSMC12-P11					PNP N.O.
E-MSMC18-N01	Threaded Type M18		2 to 8 mm (Adjustable distance)	Shielded	NPN N.O.
E-MSMC18-P01					PNP N.O.
E-MSMC18-N11			2 to 15 mm (Adjustable distance)	Non Shield	NPN N.O.
E-MSMC18-P11					PNP N.O.
