Film Thermal Cutter

Specifications and Features

Purpose/Function

Assembly/Processing

A mechanism that cuts resin films by controlling the temperature using cartridge heaters.
Mainly used to supply heat locally.
Provides heat accurately and efficiently by achieving optimal performance during the production and manufacturing process.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Components	Economy Type Number	Specification	Quantity	Unit Price
①	Cartridge Heater	E-MCHK6-40-V220-W80	Diameter: 6mm Length: 40mm Rated capacity: 80W	2	MYR 47.38/Unit
②	Temperature Sensor	C-MSND3-30	Protective cover/tube diameter d(φ): 3mm Protective tube length: 30mm	1	MYR 62.08/Unit
③	Insulation Plate	E-HIPLA-70-20-5	Standard type (heat resistance up to 220°C) Length: 70mm Width: 20mm Thickness: 5mm	1	MYR 6.74/Unit
④	Heat Shrink Tube	MTUBE-B-1	Flame resistance: Yes Inner diameter (before shrinkage): 1.5mm Inner diameter (after shrinkage): ≤0.65mm Packaging specification: 100 meters/roll	1	MYR 21.00/Unit
⑤	Temperature Controller	C-MTCTRS	Relay/voltage output freely switchable	1	MYR 148.42/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Cartridge Heaters Standard Type MYR 47.38 /Unit Shipping: 1 Day

2 Temperature Sensors High Temperature K-Thermocouple MYR 62.08 /Unit Shipping: 1 Day

3 Heat Insulating Plates Normal Grade, Temperature Resistance Within 220 °C MYR 2.88 /Unit Shipping: 13 Days

4 Heat Shrink Tubes Flame Retardant, Shrinkage2:1 MYR 21 /Unit Shipping: 1 Day

5 Temperature Controllers Standard Type MYR 148.42 /Unit Shipping: 1 Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
