Precision Visual Inspection Using Camera

Specifications and Features

Purpose/Function

Transport/Movement Positioning/Clamp Inspection/Measurement

Reproducibility of positioning of manual jigs.
Set the workpiece and secure it with a toggle clamp, then visually inspect the monitor image using a camera.
Toggle clamps are selected as top and bottom types for workpieces that can only be held by their upper and lower surfaces.
Environment/Operability: A mechanism that sets the workpiece in a wide space using a linear guide, moves it under the camera, and secures it with a toggle clamp.

Precision Visual Inspection Using Camera

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Toggle Clamp	C-LD-201HB	Clamp bolt size: M5 Material: Steel (body), Steel (bolt) Clamping pressure (N): 400	1	MYR 8.76/Unit
②	Set Screw	E-GMSSU5-8	Screw nominal (M): 5 Length L(mm): 8 Material: Stainless steel RoHS10 compliant	2	MYR 0.25/Unit
③	Toggle Clamp	C-LD-201A	Clamp bolt size: M4 Material: Nylon (body), Nylon (bolt) Clamping pressure (N): 264	2	MYR 6.99/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Toggle Clamps Horizontal, Hold Down Pressure 400N, Standard MYR 8.76 /Unit Shipping: 1 Day

2 Hex Socket Set Screws - Cup Point, Stainless Steel[RoHS Comliant] MYR 0.22 /Unit Shipping: 4 Days

3 Toggle Clamps Horizontal, Hold Down Pressure 264N MYR 6.99 /Unit Shipping: 1 Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
