Linear Guide Mechanism
Specifications and Features
- Purpose/Function
-
Return/Move
Positioning/Clamping
A traditional form and configuration of a linear mechanism using cylinders and ball screws.
It enables horizontal movement of workpieces and mechanisms on the table to multiple positions.
With a ball screw-driven linear mechanism, it allows for multi-point stops, and height adjustment blocks align the mounting surfaces of the linear guide and table.
The table moves without needing to consider the housing, thanks to the linear bushing housing unit type.
It enables horizontal movement of workpieces and mechanisms on the table to multiple positions.
With a ball screw-driven linear mechanism, it allows for multi-point stops, and height adjustment blocks align the mounting surfaces of the linear guide and table.
The table moves without needing to consider the housing, thanks to the linear bushing housing unit type.
※ This example is for design reference only. Equipment components may differ from the actual shape.
| No. | Components | Economy Model Number | Specification | Quantity | Unit Price |
|---|---|---|---|---|---|
| ① | Support Unit - Fixed Side | C-TEK15 | Type: Fixed side Shaft diameter D(φ): 15 Material: Steel Surface treatment: Black oxide coating |
1 | MYR 91.21/Unit |
| ② | Support Unit - Supported Side | C-TEF15 | Type: Support side Shaft diameter D(φ): 15 Material: Steel Surface treatment: Black oxide coating |
1 | MYR 37.15/Unit |
| ③ | Linear Bushing - Double-Flange | E-LBH20LUU | Inner circle diameter dr(φ): 20 Total length L(mm): 80 Outer tube material: Iron Outer tube surface treatment: None |
2 | MYR 35/Unit |
| ④ | Support Unit - Supported Side | C-TFF15 | Type: Support side Shaft diameter D(φ): 15 Material: Steel Surface treatment: Black oxide coating |
1 | MYR 29.80/Unit |
| ⑤ | Support Unit - Fixed Side | C-TFK15 | Type: Fixed side Shaft diameter D(φ): 15 Material: Steel Surface treatment: Black oxide coating |
1 | MYR 94.32/Unit |
| ⑥ | Linear Bushing Housing Unit | E-LBHN16 | Inner circle diameter dr(φ): 16 Total length L(mm): 44 Outer tube material: Steel Housing unit material: Aluminum alloy |
2 | MYR 25.08/Unit |
※ Kindly check MISUMI eCatalog for latest information.
Product List
1
2
3
4
5
6
※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
